>>>型号:1756-L65 控制器 用于自动化系统 多种ControlLogix机箱兼容
【功能描述】
1756-L65是B系列ControlLogix控制器。这款控制器具有内置的RS-232串行端口，以及32MB的用于数据和逻辑的用户存储器和478KB的I/O存储器。此外，它支持安装可选的非易失性存储器，但只能安装128MB CompactFlash 1756-CF128存储卡。
1756-L65的大模拟I/O为4000，大数字I/O，以及大总I/O为128,000。在5.1V DC时，它消耗1200mA的电流，而在24V DC时，它消耗14mA的电流。其功耗为3.5W，散热为11.9 BTU/hr，并具有30V的连续隔离电压。
1756-L65与多种ControlLogix机箱兼容，如1756-A4、1756-A7、1756-A10、1756-A13和1756-A17。其电池选择也受到限制，只能使用1756-BA2锂电池。
在设计和安装方面，1756-L65的模块化设计使得用户可以独立选择I/O、端子类型和网络接口。该系列还包括POINT Guard I/O安全级I/O模块，这些模块可在标准POINT I/O系统中并排使用。它的紧凑型设计使得在有限面板空间中进行安装更为容易。
1756-L65支持多种网络连通性，包括ControlNet、DeviceNet、EtherNet/IP及其他开放式网络。它的可配置性和诊断功能使得POINT I/O易于应用。它还支持带电插拔（RIUP），这意味着在系统运行期间可以更换模块。同时，它既可以水平安装也可以垂直安装，无需降额。
>>>>型号:1756-L65 控制器 用于自动化系统 多种ControlLogix机箱兼容
【英文介绍】
The 1756-L65 is a B-series ControlLogix controller. The controller has a built-in RS-232 serial port, as well as 32MB of user memory for data and logic and 478KB of I/O memory. In addition, it supports the installation of
optional non-volatile memory, but can only install 128MB CompactFlash 1756-CF128 memory cards.
The 1756-L65 has a large analog I/O of 4000, a large digital I/O, and a large total I/O of 128,000. At 5.1V DC, it consumes 1200mA of current, while at 24V DC, it consumes 14mA of current. It has a power consumption
of 3.5W, heat dissipation of 11.9 BTU/hr, and a continuous isolation voltage of 30V.
The 1756-L65 is compatible with a variety of ControlLogix chassis, such as the 1756-A4, 1756-A7, 1756-A10, 1756-A13, and 1756-A17. Its battery options are also limited, with only 1756-BA2 lithium batteries available.
In terms of design and installation, the modular design of the 1756-L65 allows the user to independently choose I/O, terminal type and network interface. The family also includes POINT Guard I/O security-level I/O modules
that can be used side-by-side in standard POINT I/O systems. Its compact design makes installation easier in limited panel space.
The 1756-L65 supports multiple network connectivity, including ControlNet, DeviceNet, EtherNet/IP, and other open networks. Its configurability and diagnostic capabilities make POINT I/O easy to apply. It also supports live
plug and plug (RIUP), which means that modules can be replaced while the system is running. At the same time, it can be installed both horizontally and vertically without derating.
