【功能描述】
1769-IQ16 是CompactLogix系列中的一款输入模块，它在工业自动化领域有着广泛的应用。这款模块具备多种功能特点，能够满足各种复杂的控制需求。
从性能参数上来看，1769-IQ16模块具有出色的电气特性。它拥有8毫秒的输入OFF/ON信号延迟时间，在5.1伏直流电时消耗115mA电流。大关闭状态电压和额定电流分别为5伏DC和1.5mA，ON额定值为10V DC和2mA。
大浪涌电流为250mA，标称输入阻抗为3kW。这些参数保证了模块在工业自动化系统中的高效稳定运行。
在机械特性方面，1769-IQ16模块具有坚固耐用的设计。它重约270克，尺寸为118 x 35 x 87毫米，采用面板安装方式。此外，它还具有IEC 2类增强绝缘类型，隔离电压为75伏直流电，在1697伏直流电下进行了1秒钟的测试
，保证了模块在恶劣的工业环境下的稳定性和安全性。
在功能应用上，1769-IQ16模块主要用于接收和处理来自各种传感器和设备的输入信号。它可以与其他CompactLogix系列的控制器和I/O模块无缝集成，实现数据的实时采集、传输和处理。这使得它在生产线控制、机器人通信
、传感器数据采集等多种场景中都能发挥重要作用。
1769-IQ16该模块还具备优异的散热性能。在开放式机箱中，其大散热量为3.55W（每小时12.11 BTU），这有助于确保模块在长时间运行过程中能够保持稳定的温度，避免因过热而影响性能或寿命。
总的来说，1769-IQ16是一款功能强大、性能稳定的输入模块，适用于各种工业自动化应用场景。它不仅能够满足复杂的控制需求，还具有出色的电气特性和机械特性，能够在恶劣的工业环境下稳定运行。
>>>>型号:1769-IQ16 输入模块 用于工业自动化和控制系统 散热性能
【英文介绍】
1769-IQ16 is an input module in the CompactLogix series, which has a wide range of applications in the field of industrial automation. This module has a variety of functional features to meet a variety of complex control needs.
From the point of view of performance parameters, the 1769-IQ16 module has excellent electrical characteristics. It has an input OFF/ON signal delay time of 8 milliseconds and consumes 115mA at 5.1 volts DC. The high shutdown
voltage and rated current are 5 volt DC and 1.5mA respectively, and ON ratings are 10V DC and 2mA. The large surge current is 250mA and the nominal input impedance is 3kW. These parameters ensure the efficient and stable
operation of the module in the industrial automation system.
In terms of mechanical properties, the 1769-IQ16 module has a rugged design. It weighs about 270 grams, measures 118 x 35 x 87 mm and is panel mounted. In addition, it has an IEC Class 2 enhanced insulation type with an isolation
voltage of 75 volts DC and a 1-second test at 1697 volts DC, guaranteeing the stability and safety of the module in harsh industrial environments.
In terms of functional applications, the 1769-IQ16 module is mainly used to receive and process input signals from various sensors and devices. It can be seamlessly integrated with other CompactLogix series controllers and I/O modules
to achieve real-time data acquisition, transmission and processing. This makes it play an important role in a variety of scenarios such as production line control, robot communication, sensor data acquisition, etc.
1769-IQ16 The module also has excellent thermal performance. In an open case, the maximum heat dissipation is 3.55W (12.11 BTU per hour), which helps to ensure that the module can maintain a stable temperature during long periods
of operation without affecting performance or life due to overheating.
Overall, the 1769-IQ16 is a powerful and stable input module for a wide range of industrial automation applications. It not only meets the complex control requirements, but also has excellent electrical and mechanical characteristics to
operate stably in harsh industrial environments.
